Cdhpower Gas Frame 3.4l/2.4l/2.75l Gas Tank Built-in Frame-gas Motorized Bicycle

Note:

1. Please clean the inner painting of the bottom bracket before you assembled the crankset
2. If buyers' bike rear wheel is with quick release,we suggest buyers do not buy the gas frame unless buyers are professional

Package include: 1pc Frame only (3.4L, 2.4L, 2.75L for choice)
3.4L Felt Faker Gas Frame (126mm Rear Width)

1. For 2-Stroke & 4-Stroke Engines.
2. Requirement on headset size:1 1/8";
3. Bottom bracket 1.732" /44mm out diameter;
4. The width and Inner Diameter(including depth of screw) of the bottom bracket: 68mmx35.4mm/2.677inx1.3937in
5. Gas Tank Cap included;
6. Kickstand Excluded
7. Rear Width: 126mm
8. Diameter of downtube:42mm
9. Requirement on switch of gas frame: 10*1.5mm
10. Required for seat post:27.2mm
11. Required for seat post clamp:31.8mm
12. Work with Disc Brake and Coaster Brake
13. For gas motorized bicycle only
14. PLEASE NOTE 1: the best safe speed if racing: 35km/h；If buyers' bike rear wheel is with quick release,we suggest buyers do not buy the gas frame unless buyers are professional

CDHPOWER Bicycle Gas Frame 3.4L For 2-Stroke & 4-Stroke Engines.

Diameter of downtube:42mm;

Requirement on seatpost:27.2mm.

Requirement on headset size:1 1/8"; Gas Tank Cap included.

Bottom bracket 1.732" /44mm diameter;

Item Weight:

11 pounds

3.4L Felt Faker Gas Frame (135mm Rear Width)

• CDHPOWER Gas Frame 3.4L Requirement on seatpost:27.2mm; Black bicycle gas frame Built-in 3.4L gas tank Designed for the 2-cycle engines 48cc/66cc/80cc
• Rear Disc brake bracket
• Rear width:135mm
• Requirement on switch of gas frame: 10*1.5mm
• Frame made especially heavy duty for gas engine applications Available with 135mm rear frame width for either single speed or multi-speed bikes.
• Bottom bracket 1.732" /44mm diameter
• Requirement on seatpost: 27.2mm;
• The width and Inner Diameter (including depth of screw) of the bottom bracket: 68mmx35.4mm/2.677inx1.3937in
• PLEASE NOTE 1: The best safe speed if racing: 35km/h
• Head tube: 150mm;
• Requirement on headset size:1 1/8"

2.4L Gas Frame
1. New reinforced GT-A with disc brake mounting ports ready on the rear end of the frame;
2. Requirement on seatpost:27.2mm3. Required for seat post clamp:31.8mm4. Head tube: 150mm; 5. Requirement on headset size: 1 1/8"; 6. Bottom bracket 2" diameter;7. Rear Width: 135mm8. 38mm diameter downtube 70 degrees angle V frame.9. The width and Inner Diameter (including depth of screw) of the bottom bracket : 68mmx51.5mm/2.677inx2in10.Note: buyers need know how to fasten the motor on the pedestal mount of gas frame to prevent crack from vibration which maybe caused crack of frame;11.CDHPOWER Reinforced Black bicycle gas frame Built-in 2.4L gas tank Designed for the 2-cycle engines 48cc/66cc/80cc with 40 to 50mm wide front mount stud spacing12.Rear Disc brake bracket and front mount pedestal works well with 8mm gas motor front mount bolts13.Frame made especially heavy duty for gas engine applications Available with 135mm rear frame width for either single speed or multi-speed bikes.14.PLEASE NOTE 1: the best safe speed if racing: 35km/h；

Rear Disc brake bracket.

Frame made especially heavy duty for gas engine applications Available with 135mm rear frame width for either single speed or multi-speed bikes.

Rear Disc brake bracket and front mount pedestal works well with 8mm gas motor front mount bolts .

Bottom bracket 2" diameter.

0.5mm thickness front mount pedestal.

CDHpower Reinforced front mount pedestal.

38mm diameter downtube 70 degrees angle V frame.

Head tube: 150mm.

Requirement on headset size:1 1/8"

Sample of gas bike w/2.4L gas frame.

This is how it looks like when you finish building the complete bike.

Item Weight : 10.15 pounds

2.75L Gas Frame
1. For 2-Stroke & 4-Stroke Engines.2. Requirement on headset size:1 1/8";
3. Bottom bracket 1.732" /44mm out diameter;4. The width and Inner Diameter(including depth of screw) of the bottom bracket: 68mmx35.4mm/2.677inx1.3937in5. Gas Tank Cap included;
6. Kickstand Excluded
7. Rear Width: 136mm
8. Diameter of downtube:42mm
9. Requirement on switch of gas frame: 10*1.5mm
10.Required for seat post:27.2mm
11.Required for seat post clamp:31.8mm
12.Work with Disc Brake
13.2.75L Frame Youtube Link: https://youtu.be/CDIm0PQo-dc
14.PLEASE NOTE 1: the best safe speed if racing: 35km/h；If buyers' bike rear wheel is with quick release,we suggest buyers do not buy the gas frame unless buyers are professional;

• Diameter of downtube:42mm;
• Required for seat post:27.2mm;
• Required for seat post clamp:31.8mm

• bottom bracket 1.732" /44mm diameter;
• the width and Inner Diameter (including depth of screw) of the bottom bracket:68mmx35.4mm/2.677inx1.3937in

• Requirement on headset size:1 1/8"
• Gas Tank Cap included
• Kickstand Excluded
